SMC® MGCMB25-250 MGC Compact Cylinder, 25 mm Cylinder Bore, 250 mm L Stroke, 288 N Max Force, Double Acting Cylinder Action, Basic Mounting

Inventory

Your Warehouse: SMC E-Commerce

Qty

Brand:	SMC^®
Cylinder Action:	Double Acting
Cylinder Bore Size:	25 mm
Dimensions:	52 mm in H x 120 mm in W x 381 mm in D
Manufacturer:	SMC Corporation of America
Maximum Force:	288 N
Mounting Type:	Basic
Name:	SMC^® MGCMB25-250 MGC Compact Cylinder, 25 mm Cylinder Bore, 250 mm L Stroke, 288 N Max Force, Double Acting Cylinder Action, Basic Mounting
Port Size:	M5 x 0.8
Pressure Rating:	0.15 to 1 mpa
Product Type:	Simple
Series:	MGC
Stroke Length:	250 mm
Temperature Rating:	-10 to 60 deg C
Type:	Compact
Unit Of Measure:	EA
Weight:	1.00
